Thermoforming Film
Thermoforming top and bottom webs are mostly used for high-speed automatic forming lines such as Multivac and ULMA etc. The bottom web can be thermal drawn to a certain depth for filling various shaped products then cap sealed with top web.
1.Outstanding forming properties.
2.Wide range of oxygen transmission rates.
3.Excellent clarity to display your product.
4.High impact and puncture resistant.
5.Retains strength at freezing temperatures.
6.Less leaks when packing rigid or sharp-edged products.
Items | Test Method | Unit | 60um | 130um | 200um | 250um |
Elongation/MD | GB/T 1040.3 | % | 669.4 | 944.6 | 843.2 | 925.4 |
Elongation/TD | GB/T 1040.3 | % | 747.6 | 867.6 | 823.6 | 760.8 |
Tensile strength/MD | GB/T 1040.3 | Mpa | 34.85 | 44.26 | 44.6 | 47.3 |
Tensile strength/TD | GB/T 1040.3 | Mpa | 44.48 | 40.82 | 44.7 | 40.2 |
Haze | GB/T 2410 | % | 4 | 3.6 | 5.17 | 7.2 |
COF | GB/T 10006 |
| 0.233-0.27 | 0.266-0.4 | 0.255-0.375 | 0.29-0.404 |
Sealing strength | QB/T 2358 | N/15mm | 23.9 | 59.3 | 69.2 | 109 |
IMPORTANT NOTICE TO PURCHASER: All statements, technical information, and recommendations contained herein are based on tests we believe to be reliable, but the accuracy or completeness thereof is not guaranteed; other sampling or test procedures may produce different values or results.
